Cooling Tower Types | Uses & Differences

If you are searching online for “cooling tower types,” then this post is for you! We will go over the five of the most commonly used tower types, including crossflow, counterflow, forced draft, induced draft and factory assembled devices.

Crossflow Cooling Towers

Because of its design, crossflow cooling towers force the hot process water to flow down the fill media. This is caused simply by the force of gravity. This process takes place at the same time as the air is being blown horizontally across the falling water, which cools it down significantly. The air flow and pattern of the water is where the crossflow model gets its name. Water will require only gravity for downward flow because there is no other present force going against it. Water will then be evenly distributed by the hot water basins located above the fills in the tower.

Counterflow Cooling Towers

Hot process water flows downward on the fill media, continuing its flow all the way onto the cold water basin. The air, though, enters in a lower section of the tower, compared to crossflow versions. From there, air will flow up, passing through the water flowing the fill. The end result here will be a cooling down phase. Pressurized pipes and nozzles are placed further apart than in crossflow towers. This is done to ensure nothing will obstruct airflow to the tower.

Forced Draft Cooling Towers

There are many benefits of using a forced draft cooling tower. And that is exactly why so many industrial plants opt for this model over the other options. Forced draft cooling towers are very powerful, yet economical at the same time. These models will remove low-potential heat that is generated in the production process. A counterflow of air combined with hot water results in a transfer of heat in the cooling fill. Paper and chemical industry plants often prefer to used forced draft cooling towers.

Factory Assembled Cooling Towers

Simple and easy transportation, installation and operation are some of the biggest reasons why plants love factory assembled towers. These versions continue to be extremely popular because they are some of the few towers that can be customized to your specific needs. Generally, these towers are used for HVAC and industrial applications where cooling efficiency is not a priority and space is limited.

Induced Draft Cooling Towers

This version features a fan at the top of tower, pulling the air upward. Fans in induced draft cooling towers then induce the hot, moist air out of the discharge. A powerful exit air velocity reduces any possible recirculation within the tower as the end result. That is the main goal for these models: to eliminate the possibility of any discharged air flowing back into the air intake area.

Cooling Tower Uses

These cooling towers are used to cool several products and machinery. Despite the various uses and machinery associated with this product, all cooling towers operate in the same way. Evaporative cooling is utilized in all circumstances.

Cooling towers are used for the following, plus many more applications:

Food and beverage service
Machine tools
Chemicals
Semi-conductors
